Configure Proxy Network In Ubuntu 22.04 And Restrict User Access

In this comprehensive guide, we will explore how to set up a proxy network in Ubuntu Linux 22.04 and how to restrict regular user access to proxy settings. This is a common requirement in corporate environments where administrators need to ensure that all network traffic is routed through a proxy server for security and compliance reasons. By implementing these measures, you can prevent users from bypassing the proxy and potentially exposing the network to security threats. This guide will cover various methods, including configuring proxy settings through the GUI, command line, and using configuration management tools. We will also discuss how to lock down these settings to prevent unauthorized changes. Let's dive into the details and ensure your network's security and compliance are maintained.

Understanding Proxy Networks

A proxy network acts as an intermediary between your computer and the internet. When you use a proxy, your internet traffic is routed through the proxy server, which then forwards it to the destination server. This setup offers several advantages, including enhanced security, improved network performance, and the ability to bypass geographical restrictions. In a corporate setting, proxies are often used to monitor and control internet usage, filter content, and prevent access to malicious websites. Understanding the role and benefits of a proxy network is crucial for implementing an effective and secure network infrastructure.

Benefits of Using a Proxy Network

1. Enhanced Security: Proxies can hide your IP address, making it more difficult for websites and attackers to track your online activity. They also provide a layer of defense against malware and phishing attacks by filtering malicious content.
2. Improved Network Performance: Proxies can cache frequently accessed content, reducing bandwidth usage and improving network speed. This is particularly beneficial in large organizations with many users accessing the same websites.
3. Content Filtering: Proxies allow administrators to block access to certain websites or content categories, ensuring compliance with company policies and preventing distractions.
4. Bypassing Geographical Restrictions: Proxies can be used to access content that is not available in your region, allowing users to bypass geographical restrictions and access global content.
5. Centralized Management: Proxies provide a central point for managing internet access, making it easier to monitor and control network traffic. This is essential for maintaining security and compliance in a corporate environment.

Configuring Proxy Settings in Ubuntu 22.04

Method 1: Using the GUI

Ubuntu 22.04 provides a straightforward graphical user interface (GUI) for configuring proxy settings. This method is suitable for users who prefer a visual approach and don't need to automate the process. To configure proxy settings via the GUI, follow these steps:

1. Open System Settings: Click on the system menu (usually located in the top-right corner) and select "Settings".
2. Navigate to Network: In the Settings window, find and click on the "Network" option.
3. Proxy Settings: In the Network settings, click on the gear icon next to your connected network (e.g., Wired or Wi-Fi). Then, select the “Proxy” tab.
4. Select Proxy Method: Choose the appropriate proxy method from the dropdown menu. The common options are “Manual”, “Automatic”, and “None”.
   • Manual: Allows you to manually enter the proxy server details, including the address and port for HTTP, HTTPS, and SOCKS proxies.
   • Automatic: Uses a proxy auto-configuration (PAC) file to automatically configure proxy settings.
   • None: Disables the use of a proxy.
5. Enter Proxy Details: If you selected “Manual”, enter the proxy server address and port for each protocol (HTTP, HTTPS, SOCKS) as required. You may also need to enter authentication details if the proxy server requires it.
6. Apply Changes: After entering the proxy details, click on the “Apply” button to save the changes. You may be prompted to enter your password to authorize the changes.
7. Verify Connectivity: Open a web browser and try accessing a website to verify that the proxy settings are working correctly. If you encounter issues, double-check the proxy settings and ensure that the proxy server is accessible.

Configuring proxy settings via the GUI is a simple and effective way to manage your network connection. However, for more advanced configurations and automation, the command line method is often preferred.

Method 2: Using the Command Line

The command line interface (CLI) offers a powerful and flexible way to configure proxy settings in Ubuntu 22.04. This method is particularly useful for scripting, automation, and setting up proxy configurations for multiple users or systems. To configure proxy settings via the command line, you can use the gsettings command, which is the primary tool for managing GNOME settings. This approach allows for granular control over proxy configurations and is ideal for system administrators who need to deploy consistent settings across multiple machines.

1. Open Terminal: Open a terminal window by pressing Ctrl + Alt + T or by searching for “Terminal” in the application menu.
2. Set Proxy Settings: Use the gsettings command to set the proxy settings. The following commands can be used to configure HTTP, HTTPS, and SOCKS proxies:

   gsettings set org.gnome.system.proxy mode 'manual'
   gsettings set org.gnome.system.proxy.http host 'your_proxy_address'
   gsettings set org.gnome.system.proxy.http port your_proxy_port
   gsettings set org.gnome.system.proxy.https host 'your_proxy_address'
   gsettings set org.gnome.system.proxy.https port your_proxy_port
   gsettings set org.gnome.system.proxy.socks host 'your_socks_proxy_address'
   gsettings set org.gnome.system.proxy.socks port your_socks_proxy_port


   Replace your_proxy_address, your_proxy_port, your_socks_proxy_address, and your_socks_proxy_port with the actual proxy server details.
3. Set Authentication (if required): If your proxy server requires authentication, you can set the username and password using the following commands:

   gsettings set org.gnome.system.proxy.http authentication-user 'your_username'
   gsettings set org.gnome.system.proxy.http authentication-password 'your_password'
   gsettings set org.gnome.system.proxy.https authentication-user 'your_username'
   gsettings set org.gnome.system.proxy.https authentication-password 'your_password'


   Replace your_username and your_password with the actual credentials. Note that storing passwords in plain text is not recommended for security reasons. Consider using a more secure method for managing credentials, such as a password manager.
4. Set Proxy Auto-Configuration (PAC) File (if applicable): If you are using a PAC file, you can configure the proxy settings using the following command:

   gsettings set org.gnome.system.proxy mode 'auto'
   gsettings set org.gnome.system.proxy autoconfiguration-url 'file:///path/to/your/proxy.pac'


   Replace /path/to/your/proxy.pac with the actual path to your PAC file.
5. Disable Proxy: To disable the proxy, use the following command:

   gsettings set org.gnome.system.proxy mode 'none'


6. Verify Settings: To verify the proxy settings, you can use the gsettings get command to retrieve the current settings:

   gsettings get org.gnome.system.proxy mode
   gsettings get org.gnome.system.proxy.http host
   gsettings get org.gnome.system.proxy.http port


7. Apply System-Wide: For system-wide settings, you can configure the /etc/environment file. Add the following lines, replacing the placeholders with your proxy details:

   http_proxy="http://your_proxy_address:your_proxy_port"
   https_proxy="http://your_proxy_address:your_proxy_port"
   ftp_proxy="http://your_proxy_address:your_proxy_port"
   no_proxy="localhost,127.0.0.1,::1"


   After modifying the /etc/environment file, you need to log out and log back in or restart the system for the changes to take effect.

The command line method provides a robust and efficient way to configure proxy settings in Ubuntu 22.04. It allows for automation and consistent deployment across multiple systems, making it an ideal choice for system administrators and advanced users.

Method 3: Using Environment Variables

Configuring proxy settings using environment variables is another effective method, particularly useful for applications that rely on these variables to determine proxy settings. This method involves setting environment variables at the system level, ensuring that all users and applications on the system use the specified proxy. To configure proxy settings using environment variables, follow these steps:

1. Edit the /etc/environment File: Open the /etc/environment file with administrative privileges using a text editor such as nano or vim. This file is used to set system-wide environment variables.

   sudo nano /etc/environment


2. Set Proxy Environment Variables: Add the following lines to the /etc/environment file, replacing your_proxy_address and your_proxy_port with your actual proxy server details:

   http_proxy="http://your_proxy_address:your_proxy_port/"
   https_proxy="http://your_proxy_address:your_proxy_port/"
   ftp_proxy="http://your_proxy_address:your_proxy_port/"
   no_proxy="localhost,127.0.0.1,::1"


   • http_proxy: Specifies the proxy server for HTTP connections.
   • https_proxy: Specifies the proxy server for HTTPS connections.
   • ftp_proxy: Specifies the proxy server for FTP connections.
   • no_proxy: Specifies a list of hosts or domains that should be accessed directly, bypassing the proxy.
3. Save and Close the File: Save the changes and close the text editor.
4. Apply the Changes: For the changes to take effect, you need to log out and log back in or restart the system. This ensures that the new environment variables are loaded.
5. Verify the Settings: After logging back in, you can verify that the environment variables are set correctly by running the following commands in the terminal:

   echo $http_proxy
   echo $https_proxy
   echo $ftp_proxy
   echo $no_proxy


   The output should display the proxy settings you configured in the /etc/environment file.

Using environment variables is a simple and effective way to configure proxy settings system-wide. This method ensures that all applications and users on the system adhere to the specified proxy configuration. However, it’s important to note that some applications may not respect environment variables, so it’s always a good practice to verify that your applications are using the proxy as expected.

Restricting User Access to Proxy Settings

In a corporate environment, it's often necessary to restrict regular users from changing proxy settings to maintain network security and compliance. There are several methods to achieve this in Ubuntu 22.04, each with its own advantages and considerations. We will explore three primary methods: using dconf, modifying file permissions, and employing configuration management tools.

Method 1: Using dconf to Lock Proxy Settings

dconf is a configuration system used by GNOME-based desktop environments, including Ubuntu. It allows you to manage and lock settings, preventing users from changing them through the GUI or command line. This method is effective for enforcing proxy settings across the system and ensuring that regular users cannot bypass the configured proxy.

1. Install dconf-editor: If it's not already installed, install dconf-editor using the following command:

   sudo apt update
   sudo apt install dconf-editor


2. Open dconf-editor: Launch dconf-editor by typing dconf-editor in the terminal or searching for it in the application menu.
3. Navigate to Proxy Settings: In dconf-editor, navigate to the proxy settings path: org -> gnome -> system -> proxy.
4. Lock the mode Setting: To prevent users from changing the proxy mode (e.g., from “Manual” to “None”), lock the mode setting. Click on the lock icon next to the mode setting. This will prevent users from modifying the proxy mode through the GUI.
5. Lock Specific Proxy Settings: If you are using a manual proxy configuration, you can also lock the specific proxy settings such as http.host, http.port, https.host, and https.port. This will prevent users from changing the proxy server address and port.
6. Apply System-Wide: To apply these settings system-wide, you can create a dconf profile. Create a new file in /etc/dconf/profile/ named user (or any other name):

   sudo nano /etc/dconf/profile/user


   Add the following content to the file:

   user-db:user


system-db:local 7. **Create a `dconf` Database**: Create a new file in `/etc/dconf/db/local.d/` named `00-proxy-settings` (or any other name): bash sudo nano /etc/dconf/db/local.d/00-proxy-settings Add the following content to the file, replacing the placeholders with your actual proxy settings: [org/gnome/system/proxy] mode='manual'

[org/gnome/system/proxy/http]
host='your_proxy_address'
port=your_proxy_port
authentication-user='your_username'
authentication-password='your_password'

[org/gnome/system/proxy/https]
host='your_proxy_address'
port=your_proxy_port
authentication-user='your_username'
authentication-password='your_password'

[/org/gnome/system/proxy]
mode='user'

[/org/gnome/system/proxy/http]
host='user'
port='user'
authentication-user='user'
authentication-password='user'

[/org/gnome/system/proxy/https]
host='user'
port='user'
authentication-user='user'
authentication-password='user'
```

8. Lock Settings in dconf Database: Create a new file in /etc/dconf/db/local.d/locks/ named 00-proxy-settings-lock (or any other name):

   sudo nano /etc/dconf/db/local.d/locks/00-proxy-settings-lock


   Add the following content to lock the settings:

   /org/gnome/system/proxy/mode
   /org/gnome/system/proxy/http/host
   /org/gnome/system/proxy/http/port
   /org/gnome/system/proxy/http/authentication-user
   /org/gnome/system/proxy/http/authentication-password
   /org/gnome/system/proxy/https/host
   /org/gnome/system/proxy/https/port
   /org/gnome/system/proxy/https/authentication-user
   /org/gnome/system/proxy/https/authentication-password


9. Update dconf Database: Update the dconf database by running the following command:

   sudo dconf update


10. Verify the Lock: Log out and log back in or restart the system. Verify that the proxy settings are locked by attempting to change them through the GUI. The settings should be grayed out or unchangeable.

Using dconf to lock proxy settings is a reliable way to enforce proxy configurations in Ubuntu 22.04. This method prevents users from bypassing the proxy and ensures that network traffic is routed through the designated proxy server.

Method 2: Modifying File Permissions

Another method to restrict user access to proxy settings is by modifying the permissions of the relevant configuration files. This approach involves changing the ownership and permissions of the files that store proxy settings, preventing regular users from modifying them directly. While this method is less flexible than using dconf, it can be effective in certain scenarios.

1. Identify Configuration Files: The primary configuration files for proxy settings are typically located in the user's home directory and the system-wide configuration directory. The relevant files include:
   • ~/.config/dconf/user: This file stores user-specific dconf settings.
   • /etc/environment: This file stores system-wide environment variables.
2. Change File Ownership: Change the ownership of the ~/.config/dconf/user file to the root user. This prevents regular users from modifying this file directly.

   sudo chown root:root ~/.config/dconf/user


3. Modify File Permissions: Modify the permissions of the ~/.config/dconf/user file to read-only for regular users. This ensures that users can read the settings but cannot modify them.

   sudo chmod 644 ~/.config/dconf/user


4. Protect /etc/environment: To protect the system-wide proxy settings, ensure that the /etc/environment file is owned by the root user and has appropriate permissions. This file should typically be read-only for regular users.

   sudo chown root:root /etc/environment
   sudo chmod 644 /etc/environment


5. Apply Changes: Log out and log back in or restart the system for the changes to take effect.

By modifying the file permissions, you can prevent regular users from directly altering the proxy settings. However, it's important to note that this method can be circumvented by users with sufficient technical knowledge. For a more robust solution, consider using dconf or configuration management tools.

Method 3: Using Configuration Management Tools

Configuration management tools such as Ansible, Puppet, and Chef provide a powerful way to manage and enforce system configurations across multiple machines. These tools allow you to define the desired state of your systems and automatically apply the necessary configurations. Using a configuration management tool is particularly beneficial in large environments where you need to ensure consistent proxy settings across many systems.

1. Choose a Configuration Management Tool: Select a configuration management tool that suits your needs. Ansible is a popular choice due to its simplicity and agentless architecture. Puppet and Chef are also widely used and offer advanced features for managing complex environments.
2. Install and Configure the Tool: Install and configure the chosen configuration management tool on your management server and target systems. Refer to the tool's documentation for detailed installation instructions.
3. Create a Configuration Script: Create a configuration script (e.g., an Ansible playbook) that defines the desired proxy settings. The script should include tasks to set the proxy settings using gsettings or environment variables and lock the settings using dconf. Here's an example Ansible playbook that sets proxy settings and locks them using dconf:

   ---
   - hosts: all
     become: true
     tasks:
       - name: Set proxy settings using gsettings
         command: gsettings set org.gnome.system.proxy mode 'manual'
       - command: gsettings set org.gnome.system.proxy.http host 'your_proxy_address'
       - command: gsettings set org.gnome.system.proxy.http port your_proxy_port
       - command: gsettings set org.gnome.system.proxy.https host 'your_proxy_address'
       - command: gsettings set org.gnome.system.proxy.https port your_proxy_port

       - name: Create dconf profile
         file:
           path: /etc/dconf/profile/user
           state: touch
           owner: root
           group: root
           mode: 0644

       - name: Set dconf profile content
         copy:
           dest: /etc/dconf/profile/user
           content: |
             user-db:user
             system-db:local

       - name: Create dconf database
         file:
           path: /etc/dconf/db/local.d/00-proxy-settings
           state: touch
           owner: root
           group: root
           mode: 0644

       - name: Set dconf database content
         copy:
           dest: /etc/dconf/db/local.d/00-proxy-settings
           content: |
             [org/gnome/system/proxy]
             mode='manual'

             [org/gnome/system/proxy/http]
             host='your_proxy_address'
             port=your_proxy_port

             [org/gnome/system/proxy/https]
             host='your_proxy_address'
             port=your_proxy_port

             [/org/gnome/system/proxy]
             mode='user'

             [/org/gnome/system/proxy/http]
             host='user'
             port='user'

             [/org/gnome/system/proxy/https]
             host='user'
             port='user'

       - name: Create dconf locks directory
         file:
           path: /etc/dconf/db/local.d/locks/
           state: directory
           owner: root
           group: root
           mode: 0755

       - name: Create dconf lock file
         file:
           path: /etc/dconf/db/local.d/locks/00-proxy-settings-lock
           state: touch
           owner: root
           group: root
           mode: 0644

       - name: Set dconf lock content
         copy:
           dest: /etc/dconf/db/local.d/locks/00-proxy-settings-lock
           content: |
             /org/gnome/system/proxy/mode
             /org/gnome/system/proxy/http/host
             /org/gnome/system/proxy/http/port
             /org/gnome/system/proxy/https/host
             /org/gnome/system/proxy/https/port

       - name: Update dconf database
         command: sudo dconf update


   Replace your_proxy_address and your_proxy_port with the actual proxy server details.
4. Run the Configuration Script: Execute the configuration script on the target systems. This will apply the proxy settings and lock them, preventing users from making changes.
5. Verify the Configuration: Verify that the proxy settings are correctly applied and locked on the target systems. You can check the settings using gsettings or by attempting to change them through the GUI.

Using configuration management tools provides a scalable and reliable way to manage proxy settings across your infrastructure. This method ensures that all systems adhere to the defined proxy configuration and that users cannot bypass the proxy.

Troubleshooting Common Proxy Issues

Setting up and maintaining a proxy network can sometimes be challenging, and you may encounter various issues. Troubleshooting these issues efficiently is crucial for ensuring smooth network operations. Here are some common proxy issues and their solutions:

1. Unable to Connect to the Internet: If you cannot connect to the internet after configuring proxy settings, the first step is to verify that the proxy server is running and accessible. Check the proxy server's status and ensure that it is not experiencing any downtime or connectivity issues.

   • Solution: Verify Proxy Server Status, Double-Check Proxy Settings, Check Firewall Rules

2. Websites Not Loading Properly: Sometimes, websites may not load properly, or certain elements may be missing when using a proxy. This can be due to incorrect proxy settings, caching issues, or content filtering rules.

   • Solution: Clear Browser Cache, Bypass Proxy for Specific Websites, Adjust Content Filtering Rules

3. Authentication Issues: If your proxy server requires authentication, you may encounter issues if the credentials are not entered correctly or if the authentication method is not supported. Incorrect usernames, passwords, or authentication protocols can prevent you from accessing the internet through the proxy.

   • Solution: Verify Credentials, Check Authentication Method, Update Credentials

4. Proxy Bypassing: Users may attempt to bypass the proxy by manually changing their proxy settings or using alternative methods. This can compromise network security and compliance.

   • Solution: Enforce Proxy Settings, Monitor Network Traffic, Educate Users

5. Application Compatibility: Some applications may not be compatible with proxy servers or may require specific configurations to work correctly. This can result in connection errors or application malfunctions.

   • Solution: Configure Application-Specific Proxy Settings, Use a Proxy-Aware Application, Update Application

Conclusion

Setting up a proxy network in Ubuntu Linux 22.04 and restricting user access to proxy settings is essential for maintaining network security and compliance in corporate environments. This guide has provided a comprehensive overview of various methods for configuring proxy settings, including using the GUI, command line, and environment variables. We have also discussed how to restrict user access to proxy settings using dconf, modifying file permissions, and employing configuration management tools.

By implementing these measures, you can ensure that all network traffic is routed through the designated proxy server, preventing users from bypassing the proxy and potentially exposing the network to security threats. Regularly reviewing and updating your proxy configurations and access restrictions is crucial for maintaining a secure and compliant network environment.

Remember, a well-configured proxy network is a critical component of your organization's security infrastructure. By following the guidelines and best practices outlined in this guide, you can effectively manage your proxy settings and protect your network from potential threats.
