The Linux kernel is a vast and complex piece of software, and sometimes developers need to extract specific functionalities from it to use in other projects or for testing purposes. This article explores how to compile stand-alone function binaries from the Linux kernel, focusing on taking snippets from kernel drivers' code—such as the drm_fb_helper_hotplug_event function inside drivers/gpu/drm/drm_fb_helper.c—and compiling them into executable binaries. This approach allows developers to isolate and test kernel functions outside the kernel environment, which can be invaluable for debugging, experimentation, and understanding the intricacies of the kernel code.

Compiling functions from the Linux kernel as stand-alone binaries is not a straightforward task due to the kernel's unique environment and dependencies. Kernel code relies on a specific set of headers, libraries, and build configurations that are not available in a standard user-space environment. Therefore, to compile kernel functions into stand-alone binaries, we need to replicate the kernel's build environment and handle its dependencies appropriately.

Kernel-Specific Dependencies

The Linux kernel operates in its own address space and has its own set of system calls and libraries. Functions within the kernel often depend on other kernel functions and data structures, which are not directly accessible from user space. When extracting a function like drm_fb_helper_hotplug_event, it's crucial to identify all its dependencies and include them in the compilation process. This typically involves including relevant header files, defining necessary data structures, and potentially implementing stub functions for unresolved symbols.

Build Environment Differences

The kernel is built using a specific toolchain and build system (typically Make) that sets various compiler flags and includes paths. These settings are essential for ensuring that the kernel code is compiled correctly. To compile stand-alone binaries, we need to mimic these settings or create a compatible environment. This might involve using the same compiler version, including the kernel headers, and defining the appropriate macros and flags.

Memory Management and Context

Kernel functions often assume they are running in a kernel context, with specific memory management and interrupt handling mechanisms in place. When running a kernel function in a stand-alone binary, these assumptions may not hold. Therefore, we might need to provide alternative implementations for memory allocation, locking, and other kernel-specific operations.

To successfully compile a stand-alone binary from the Linux kernel, follow these steps:

  1. Identify the Function and Dependencies: The first step is to identify the function you want to compile and analyze its dependencies. Use tools like cscope or ctags to trace the function's calls and data structure usage. For drm_fb_helper_hotplug_event, examine the source code to understand which headers and functions it depends on. This function, part of the Direct Rendering Manager (DRM) subsystem, likely depends on DRM-specific headers and functions related to framebuffer management and hotplug events.

  2. Include Necessary Headers: Copy the required header files from the kernel source tree to your project directory. These headers define the data structures and function prototypes that the kernel function uses. For DRM functions, you'll likely need headers from include/drm and drivers/gpu/drm.

  3. Create a Stand-Alone Source File: Create a new C file that includes the function you want to compile and any necessary supporting code. This file will serve as the entry point for your stand-alone binary. You might need to write a main function to call the kernel function and set up any required context.

  4. Implement Stub Functions: If the kernel function calls other kernel functions that are not available in your stand-alone environment, you'll need to implement stub functions. These stubs provide minimal implementations to satisfy the linker and allow the code to compile. For example, if drm_fb_helper_hotplug_event uses kernel memory allocation functions like kmalloc or kfree, you'll need to provide stubs for these functions.

  5. Set Up the Build Environment: Configure your build environment to mimic the kernel's. This includes setting the correct compiler flags, include paths, and linker options. You can often find these settings in the kernel's Makefiles. Using the same compiler version as the kernel can also help avoid compatibility issues.

  6. Compile the Binary: Use a compiler like GCC to compile your source file and link it with any necessary libraries. You'll need to specify the include paths for the kernel headers and any other dependencies. The compilation command might look something like this:

    gcc -o my_binary my_source_file.c -I/path/to/kernel/include -I/path/to/kernel/drivers/gpu/drm -Wall -Werror

  7. Run and Test: Once the binary is compiled, you can run it and test the extracted function. You might need to provide some input data or set up a specific environment for the function to work correctly. For example, testing drm_fb_helper_hotplug_event might involve simulating a hotplug event and checking how the function responds.

Let's walk through a practical example of compiling the drm_fb_helper_hotplug_event function as a stand-alone binary.

Step 1: Identify Dependencies

The drm_fb_helper_hotplug_event function is located in drivers/gpu/drm/drm_fb_helper.c. Analyzing its source code, we can identify several dependencies:

  • Headers: drm.h, drm_fb_helper.h, drm_crtc_helper.h
  • Functions: Various DRM functions like drm_for_each_connector, drm_connector_status_connected, drm_crtc_helper_set_mode, and kernel functions like kfree and mutex_lock/mutex_unlock.
  • Data Structures: Structures like struct drm_fb_helper, struct drm_connector, and struct drm_crtc.

Step 2: Include Necessary Headers

Copy the necessary header files from the kernel source tree to your project directory. This might involve creating a directory structure that mirrors the kernel's include paths.

mkdir -p include/drm
cp /path/to/kernel/include/drm/*.h include/drm/
cp /path/to/kernel/drivers/gpu/drm/drm_fb_helper.h include/drm/
cp /path/to/kernel/drivers/gpu/drm/drm_crtc_helper.h include/drm/

Step 3: Create a Stand-Alone Source File

Create a C file (e.g., test_hotplug.c) that includes the function and any necessary supporting code. This file will include the DRM headers and a main function to call drm_fb_helper_hotplug_event.

#include <stdio.h>
#include <stdlib.h>
#include <stdbool.h>
#include "include/drm/drm.h"
#include "include/drm/drm_fb_helper.h"
#include "include/drm/drm_crtc_helper.h"

// Stub implementations for kernel functions
void kfree(const void *ptr) {
    free((void*)ptr);
}

void mutex_lock(struct mutex *lock) {
    // Implement mutex locking if needed
}

void mutex_unlock(struct mutex *lock) {
    // Implement mutex unlocking if needed
}

// Dummy data structures
struct drm_fb_helper {
    // Add necessary fields
};

struct drm_connector {
    // Add necessary fields
};

struct drm_crtc {
    // Add necessary fields
};

bool drm_connector_status_connected(int status){
    return true; // replace with actual implementation or stub
}

void drm_for_each_connector(struct drm_fb_helper *fb_helper, void (*callback)(struct drm_connector *, void *), void *data) {
    // Iterate through connectors and call the callback
}

int drm_crtc_helper_set_mode(struct drm_crtc *crtc, struct drm_display_mode *mode, int x, int y) {
    return 0; // Dummy implementation
}

// Include the drm_fb_helper.c source directly
#include "/path/to/kernel/drivers/gpu/drm/drm_fb_helper.c"

int main() {
    struct drm_fb_helper *fb_helper = malloc(sizeof(struct drm_fb_helper));
    if (!fb_helper) {
        perror("Failed to allocate fb_helper");
        return 1;
    }

    // Initialize fb_helper if needed

    drm_fb_helper_hotplug_event(fb_helper);

    free(fb_helper);
    return 0;
}

Step 4: Implement Stub Functions

Provide stub implementations for kernel functions like kfree, mutex_lock, and mutex_unlock. These stubs are necessary because the stand-alone binary doesn't have access to the kernel's memory management or locking mechanisms. You may also need to provide dummy implementations for DRM-specific functions and data structures.

Step 5: Set Up the Build Environment

Set up your build environment by specifying the include paths and compiler flags. You can create a Makefile to automate the build process.

obj-m := test_hotplug.o

KDIR := /lib/modules/$(shell uname -r)/build

all:
	make -C $(KDIR) M=$(PWD) modules

clean:
	make -C $(KDIR) M=$(PWD) clean

CC = gcc
CFLAGS = -I./include -Wall -Werror

test_hotplug: test_hotplug.c
	$(CC) $(CFLAGS) -o test_hotplug test_hotplug.c

clean:
	rm -f test_hotplug

Step 6: Compile the Binary

Compile the binary using the Makefile or the command line.

make test_hotplug

Step 7: Run and Test

Run the compiled binary and observe the output. You might need to set up a specific environment or provide input data for the function to work correctly. In this case, you might need to simulate a DRM environment and hotplug event.

Kernel Code Evolution

The Linux kernel is constantly evolving, with new features, bug fixes, and API changes being introduced regularly. When compiling stand-alone binaries, it's essential to ensure that the code remains compatible with the kernel version you're targeting. This might involve tracking kernel changes and updating your code and build environment accordingly.

Licensing and Distribution

The Linux kernel is licensed under the GNU General Public License (GPL), which imposes certain requirements on the distribution of derivative works. If you're compiling and distributing stand-alone binaries derived from the kernel, you need to comply with the GPL terms. This typically involves providing access to the source code and ensuring that any modifications are also licensed under the GPL.

Debugging and Testing

Debugging stand-alone binaries compiled from the kernel can be challenging due to the differences between the kernel and user-space environments. Standard debugging tools like GDB can be used, but understanding the context and interactions within the kernel code often requires specialized knowledge. Thorough testing is crucial to ensure that the extracted functions work correctly in the stand-alone environment.

Memory Management Issues

Kernel functions often rely on specific memory management mechanisms that are not available in user space. When compiling stand-alone binaries, you might need to provide alternative memory allocation and deallocation routines. This can be complex, especially if the kernel function uses advanced memory management techniques.

Kernel Modules

Instead of compiling stand-alone binaries, you might consider creating kernel modules. Kernel modules are dynamically loadable pieces of code that can be inserted into and removed from the running kernel. This approach allows you to test kernel code in its native environment without having to recompile the entire kernel.

Fuzzing

Fuzzing is a testing technique that involves providing random or malformed input to a program to identify bugs and vulnerabilities. Fuzzing can be a valuable tool for testing stand-alone binaries compiled from the kernel. By fuzzing the extracted functions, you can uncover potential issues that might not be apparent through manual testing.

Formal Verification

Formal verification is a technique that uses mathematical methods to prove the correctness of software. Formal verification can be used to verify the behavior of kernel functions and ensure that they meet specific requirements. While formal verification can be complex and time-consuming, it can provide a high level of assurance about the correctness of the code.

Compiling stand-alone function binaries from the Linux kernel is a complex but valuable technique for developers who need to isolate and test specific kernel functionalities. By understanding the kernel's dependencies, setting up the correct build environment, and handling memory management and context issues, you can successfully extract and compile kernel code into executable binaries. While there are challenges and considerations, the ability to test kernel functions in isolation can significantly aid in debugging, experimentation, and understanding the intricacies of the kernel code. This approach, combined with alternative techniques like kernel modules, fuzzing, and formal verification, can enhance the robustness and reliability of kernel-derived applications and systems.

By following the steps and considerations outlined in this article, developers can effectively leverage kernel code in various projects while adhering to licensing requirements and maintaining code quality.
